| Model | Marvel inverter 70 | Marvel inverter 90 | Marvel inverter 120 | Marvel inverter 150 | Marvel inverter 200 | Marvel inverter 260 | |
| Advised pool volume | m³ | 20-35 | 25-40 | 35-55 | 50-75 | 60-85 | 80-115 |
| Heating temperatuer range | °C | 15~40 | 15~40 | 15~40 | 15~40 | 15~40 | 15~40 |
| Cooling temperatuer range | °C | 8~28 | 8~28 | 8~28 | 8~28 | 8~28 | 8~28 |
| Operating range | °C | -10~43 | -10~43 | -10~43 | -10~43 | -10~43 | -10~43 |
| Air 26°C Water 26°C Inverter Mode | Capacity(KW) | 7.00~1.78 | 9.00~2.27 | 12.0~3.00 | 15.0~3.77 | 20.0~5.00 | 26.0~6.71 |
| Power input(KW) | 1.12~0.108 | 1.44~0.138 | 1.92~0.182 | 2.40~0.229 | 3.20~0.303 | 4.15~0.406 | |
| Input current(A) | 4.97~0.48 | 6.39~0.61 | 8.52~0.81 | 4.08~0.39 | 5.43~0.52 | 7.05~0.69 | |
| COP | 16.48~6.25 | 16.45~6.25 | 16.48~6.25 | 16.46~6.25 | 16.50~6.25 | 16.53~6.27 | |
| Air 15°C Water 26°C Inverter Mode | Capacity(KW) | 5.00~1.43 | 7.00~1.78 | 9.00~2.35 | 12.0~2.95 | 15.0~3.85 | 20.0~5.11 |
| Power input(KW) | 1.11~0.203 | 1.55~0.253 | 2.00~0.331 | 2.65~0.418 | 3.33~0.546 | 4.43~0.728 | |
| Input current(A) | 4.92~0.90 | 6.88~1.12 | 8.87~1.47 | 4.50~0.71 | 5.65~0.93 | 7.52~1.24 | |
| COP | 7.04~4.50 | 7.04~4.52 | 7.10~4.50 | 7.06~4.53 | 7.05~4.50 | 7.02~4.51 | |
| Air 35°C Water 27°C | Capacity(KW) | 3.00~1.85 | 4.00~2.39 | 5.30~3.04 | 7.00~3.82 | 9.00~4.99 | 12.0~4.93 |
| Power input(KW) | 0.99~0.38 | 1.33~0.47 | 1.76~0.61 | 2.31~0.77 | 3.00~1.01 | 4.00~1.05 | |
| Input current(A) | 4.39~1.69 | 5.90~2.09 | 7.81~2.71 | 3.92~1.31 | 5.09~1.72 | 6.79~1.79 | |
| EER | 4.87~3.03 | 5.09~3.01 | 4.98~3.01 | 4.96~3.03 | 4.94~3.00 | 4.70~3.00 | |
| Power supply | 220-240V~ /50Hz | ||||||
| Max power input | KW | 1.8 | 1.8 | 2.2 | 2.8 | 3.5 | 4.7 |
| Max Current | A | 8.0 | 8.0 | 10.0 | 12.0 | 15.0 | 20.0 |
| Water flow | m³/h | 2.5 | 3.1 | 4.0 | 5.1 | 6.6 | 8.7 |
| Refrigerant volume | R32/0.34kg | R32/0.45kg | R32/0.55kg | R32/0.7kg | R32/0.9kg | R32/1.25kg | |
| Min pressure/max pressure | 1.5/4.15MPa | 1.5/4.15MPa | 1.5/4.15MPa | 1.5/4.15MPa | 1.5/4.15MPa | 1.5/4.15MPa | |
| Unit net dimensions | mm | 320×320×370 | 950/274/653 | 950/274/653 | 950/274/653 | 1098*396*735 | 1098*396*735 |
| Package dimensions | mm | 360×360×400 | 970/430/788 | 970/430/788 | 970/430/788 | 1131/475/875 | 1131/475/875 |
| Net weight | kg | 36 | 40 | 42 | 44 | 49 | 70 |
| Gross weight | kg | 45 | 50 | 52 | 54 | 59 | 81 |
| Noise at 1 m | dB(A) | 38~46 | 39~47 | 40~48 | 41~50 | 42~51 | 43~52 |
| Noise at 10m | dB(A) | 19~27 | 20~28 | 21~29 | 23~31 | 24~32 | 24~33 |
| Compressor brand | GMCC | ||||||
| Compressor type | Single-Rotary | Single-Rotary | Twin-Rotary | Twin-Rotary | Twin-Rotary | Twin-Rotary | |
| Water proof level | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | |
| Loss charge | (mCE) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 |
